PM60 series open compact module
PM60 series open compact module

PM60 series open compact module

Email

cathy@bzd-linearmotor.com

Inquiry Now
Related Product
  • Product Detail
  • Technical parameter
  • Product characteristics
  • File Download

  • Electrical parameter

    Parameter

    Round rod

    Model

    D16-080

    D16-110

    D16-140

    Sustained thrust N

    10

    15

    20

    Peak thrust N

    40

    60

    80

    Continuous current Arms

    0.62

    Peak current Arms

    2.5

    Pole distance mm

    60

    Maximum speed M/S

    1

    1.5

    2

    Maximum acceleration G

    1

    1.5

    2

    Module mechanical parameters

    Parameter

    Round rod

    Model

    D16-080

    D16-110

    D16-140

    Module total height A (mm)

    76

    Module maximum stroke (mm)

    400

    Slide Length B (mm)

    100

    130

    160

    Effective stroke S (mm)

    25*N（N=1、2、3......16)





    Avoidance stroke S2(mm)

    25

    Mounting hole spacing C(mm)

    40

    55

    60

    Limit end distance D (mm)

    35

    Base mounting hole spacing (mm)

    60

    Note: If special size is required, it can be customized upon request
