Electrical parameter
Parameter Slab U-shape Model FA60-109 FA60-157 FA60-205 FA80-109 FA80-157 FA80-205 UI3-61 UI3-121 UI3-181 UI3-241 Sustained thrust N 92 132 172 138 200 260 36 72 108 144 Peak thrust N 300 452 604 471 720 948 144 288 432 576 Continuous current Arms 3.4 3.2 3.2 3.3 3.3 3.1 2.3 Peak current Arms 14 9.2 Pole distance mm 24 60 Maximum speed M/S 3 3.5 4 3.5 4 4 2.5 3 3 3.5 Maximum acceleration G 3 3.5 4 3.5 4 4.5 2.5 3 3 3.5 Module mechanical parameters
Parameter Slab U-shape Model FA60-109 FA60-157 FA60-205 FA80-109 FA80-157 FA80-205 UI3-61 UI3-121 UI3-181 UI3-241 Module total height A (mm) 92 Module maximum stroke (mm) 4000 Slide Length B (mm) 140 170 220 140 170 220 140 140 200 260 Effective stroke S (mm) 25*N（N=1、2、3......160) Avoidance stroke S2(mm) 10 Mounting hole spacing C(mm) 60 75 100 60 75 100 60 60 90 120 Limit end distance D (mm) 22 Base mounting hole spacing (mm) 120 Note: If special size is required, it can be customized upon request
