PM85 series open compact modules
PM85 series open compact modules

PM85 series open compact modules

Email

cathy@bzd-linearmotor.com

Inquiry Now
Related Product
  • Product Detail
  • Technical parameter
  • Product characteristics
  • File Download

  • Electrical parameter

    Parameterslab
    ModelFA40-109FA40-157FA40-205
    Sustained thrust N527597
    Peak thrust N171258345
    Continuous current Arms3.43.23.2
    Peak current Arms14
    Pole distance mm24
    Maximum speed M/S2.533.5
    Maximum acceleration G2.533.5

    Module mechanical parameters

    Parameterslab
    ModelFA40-109FA40-157FA40-205
    Module total height A (mm)106
    Module maximum stroke (mm)4000
    Slide Length B (mm)120170220
    Effective stroke S (mm)25*N（N=1、2、3......160)  
    Avoidance stroke S2(mm)10
    Mounting hole spacing C(mm)5075100
    Limit end distance D (mm)22
    Base mounting hole spacing (mm)120

    Note: If special size is required, it can be customized upon request
